Features

LED speaker diagnostics
Wail, Yelp, Air Horn, Phaser, Manual, and Two Tone
Self-resetting circuit protections against speaker shorts
Integrated public address microphone
Seven light functions
Dual color backlighting on keypad (Amber & Red)
Four position progressive slide switch with LED indicators
Park Kill input
Auxiliary input
Positive locking wiring harness included
Replaceable jumpers for option selection
Positive and negative switching for AUX and PKILL inputs
High and Low voltage shutdown protection
30 Standard function replaceable labels
Drives one or two 100 Watt speakers

Spécifications

Size: 3"H X 6"W X 6 1/2"D
Weight: 6 lbs.
Output: 100 or 200 Watts (1 or 2 speakers)
Voltage: 10V-16V DC
Frequency: 675-1633 Hz
Amp. Draw: 8 Amps (per speaker)\
Approvals: Exceeds Acoustical and environmental requirements of SAE J1849*, California Title 13 Class A* (* when used with SVP drivers and approved tones)
